イメージスタジオ109は、W杯サッカーをはじめ世界のスポーツシーンで活躍している「スパイダーカム(Spidercam)」の日本エージェントとして、スポーツフィールドやコンサートスタジアムで、視点が自由に空間を飛びまわる夢のようなカメラワークを提供しています。また日本最大級の「アキラクレーン」3軸で小型軽量な「ミニスコーピオ・リモートヘッド」ユニークな回転軸をもつ「フライトヘッド5スタビライザヘッド」2つのアーム長が選べる「ミレニアム35/44」など、各種機材のオペレーションサービスでTV-CMを始め様々な現場で日々プロフェッショナルの高度な要求にお応えしています。
Set-up time | 30min |
Internal dimensions (H x W x D) | 25in. x 12in. x 17in. / 64cm x 31cm x 43cm |
External dimensions (H x W x D) | 39.5in x 22in. x 30in. / 100cm x 56cm x 76cm |
Weight without mount | 57lbs / 26kg |
Weight with hard mount | 61lbs / 28kg |
Weight with Iso-Damper mount | 66lbs / 30kg |
Max. load | 77lbs / 35kg |
Pan | 360°continuous |
Tilt | +80°/-155° |
Roll 340° | Clockwise:+110° Anti-Clockwise:-230° |
Outputs at camra plate | 2 x 75ohm BNC 1 x 12V lens scale cam 1 x 14V @ 10amps peak 1 x 30V unregulated @ 15amps peal Zoom output Focus output Iris output Camera start/stop 1 x Aux-CAC/RCU/LCS through sliprings |
Recommended for | Tracking vehicles/Wirecam/Strada/ Telescopic Techno Cranes/GF-16/GF-14/GF-6 |
Advantages | Only 3 axis head to roll with any 35mm camera fitted with any 1000ft mag 'smart pan & tilt' facility. Hole through pan axis allows maximum compatibility with any camera, cables for all High Defenition Cameras and Triax can be feed through without cable getting tangled up like other slipring only remoteheads. |
Mount bass | Standard Mitchell |
4th axis |
Weight in 2 axis | 18Kg |
Weight in 3 axis | 25Kg |
Max Load in 2axis | 45Kg |
Max Load en 3axis | 20Kg |
The movement in all 3 axis (Pan. Tilt and Roll) is 360°contiunes and includes |
|
Power from battery or power supply (included) | 24V to 35V/10A |
1 connection for Scorpio Focus, Video lens control or other lens control systems | |
2 out 12V/12.5A for normal or high speed cameras | |
1 out 26.7V/12.5A for normal or high speed cameras | |
Max. speed in all axis 2.5 sec for 360 degrees |
オーストリアとドイツで共同開発されたスパイダーカム(Spidercam)は、4隅の滑車とケプラーロープで吊り下げられた中央のカメラユニットが4台のウインチコントロールでその空間内を自由に飛びまわりながら撮影することができ、安全性・静粛性に優れたカメラシステムです。イメージスタジオ109は2007年より日本のエージェントとして日本国内でスパイダーカム(Spidercam)を運用しています。 現在、スパイダーカム(Spidercam)は12台のシステムが世界中で活躍しており、FIFAワールドカップやオリンピック、フィギュアスケートなど各種スポーツの世界選手権大会中継では必ず使用されるほど認知されています。近年では日本国内でもスタジアムライヴやミュージックビデオなど数々の実績を重ねています。
